【 Specification 】
Operating System | TelemetryOS |
---|---|
Storage | 128GB On-Board eMMC |
Video Output | Dual HDMI 4K Video @60Hz |
Maximum Resolution | 4096 x 2160 Pixels per HDMI |
Audio Output | 1x 3.5mm Audio Combo Jack |
Ethernet | 1x Gigabit LAN Port |
Wireless Type | 802.11ax |
WiFi | WiFi 6 Dual Band (2.4GHz/5.8GHz) |
Anti-Theft System | 1x Kensington Lock Slot |
Power Input | 1x USB Type-C |
Power Supply | 12V/2A DC (Voltage Range 12V-23V), US Plug |
Mount Type | VESA |
Dimensions | 5.2"L x 3.2"W x 0.72"H |
Weight | 0.45 lb |
Package Includes
- 1* Mini PC
- 1* Power Supply with EU/AU/US/UK Type Adapters (Adapters will be selected based on sales regions)
- 1* User Manual
- VESA mount kits
Warranty
We offer 12-month warranty for the hardware of each product under normal usage excluding deliberate damage, accidents, misuse on the product or damage caused by repairs or upgrades attempted by any unauthorized person.
After-sales Service
We offer 7x24 hours online service, please email us at store@mele.cn anytime when you need a support.
FAQ of TelemetryOS Box Mini Computer
1. Can it be powered by power bank? Can it be used with other type-C power supply?
This Mini PC needs stable 12V2A power supply, it must be connected with MeLE original type-C power supply. Please don't power it by the power bank.
2. How to enter into BIOS Setting?
Press the power button and press F7 or Delete continuously to enter select boot device menu -> select Enter Setup and press Enter.
3. How to set Auto power on?
Step 1, Press the power button and press F7 or Delete continuously to enter select boot device menu -> select Enter Setup and press Enter to enter into BIOS Setting menu.
Step 2, Select Chipset -> Common Function -> Power on by auto or Manual-> Select Auto Power on .
Step 3, Then go to Save & Exit -> Save Changes and Exit -> Yes to complete this setting.
4. How to start up TelemetryTV?
Each MeLE Mini PC has preinstalled TelemetryTV, please enter http://help.telemetrytv.com Search for Start Up. TelemetryTV does not recommend using two displays at the same time unless displaying simple static images only.
5. Can it run Linux Ubuntu?
Yes, it supports Linux Ubuntu OS.
6. If you have any other questions, please send email to store@mele.cn
